1993 Alfa Romeo 155 V6 TI

In 1993, Alfa Corse prepared a radical version of their 155 for the Deutsche Tourenwagen Meisterschaft (DTM) racing series. The effort was quite successful and the model later became one of the winning in DTM.

In the first season Nicola Larini won half of all the races outright, and placed first overall in the series. The company retains his car which is currently on permanent display in their museum.

Throughout the seasons, Alfa Corse updated the 155 TI. In 1996 the car got a 2.5-litre 90° V6 for the newely formed International Touring Car Championship.

Engine
Configuration 60º V6
Location Front, longitudinally mounted
Construction light alloy block and head
Displacement 2,498 cc / 152.4 cu in
Bore / Stroke 93.0 mm (3.7 in) / 61.3 mm (2.4 in)
Compression 12.5:1
Valvetrain 4 valves / cylinder, DOHC
Fuel feed Weber Marvelling Fuel Injection
Aspiration Naturally Aspirated
Power 420 bhp / 313 kW @ 11,500 rpm
Torque 294 Nm / 217 ft lbs @ 8,000 rpm
BHP/Liter168 bhp / liter
Drivetrain
Chassis unitary steel
Suspension (fr/r)transverse arms, McPherson struts, coil springs, telescopic dampers, driver adjustable anti-roll-bar
Steering rack-and-pinion, power assisted
Brakes ventilated discs, all-round, ABS
Gearbox 6 speed Sequential
Drive All wheel drive
Dimensions
Weight 1,100 kilo / 2,425 lbs
Length / Width / Height 4,576 mm (180.2 in) / 1,750 mm (68.9 in) / 1,410 mm (55.5 in)
Wheelbase / Track (fr/r) 2,540 mm (100 in) / 1,460 mm (57.5 in) / 1,460 mm (57.5 in)
